The footsteps of giants...


It occurs to me that most people don't understand the plight of the sailor, the call of the sea. They think that sailing is a form of transportation. Well, I suppose it is, but sailing is not just going from place to place in a boat with sails - it is more than that.

The sailor strikes a compromise between the will of man and that of God - Between the ideal course and the fate that the unflinching elements of wind and water would put upon him.

On even the shortest foray upon the rolling heap, the sailor must not only contend with the adversities of wind and sea, but harness those very same forces - to bend the strength of the elements to his endeavor.

Command of a ship under sail is walking within the province of deity, yet with humility before the sea and her moods, earned without quarter in the trials of countless souls who have gone before.

This respect for mother ocean, for Neptune and his kin, or for the will of the one God comes from the simple fact that man must compromise to guide his vessel to ports afar, but the Sea suffers no such indignity. For the Sea bends not to the will of man, rather it remains unchanged, wild and ever renewed, suffering not even the footprints of giants if left within its surging reach.

Yet, for all its wildness, this fearsome, ever changing frontier tolerates the gentle wisp of a ship upon its face, but only if the respect due is paid - for the Sea has a peculiar hunger for the foolish and arrogant, for the unprepared and the unwary.

Fair winds, Gentle Reader, and may the seas nudge you gently from astern.

posted by CT | 10:26 PM

0 Comments:

Post a Comment

<< Home

Introducing Propcalc 4.0

Use Propcalc to easily match your hull with your engine, transmission, and propeller
Put the known data in the top fields, then hit the Update button to get the answers.
Results, of course, should be verified by a Naval Architect or qualified surveyor.
Data is provided for three bladed propellers of average type
For two or four bladed props, use the modifiers shown below.

Fill out the fields as follows:

Vessel LWL (ft) = Waterline length
Vessel Disp (lbs) = Vessel displacement
(max) HP = Rated Engine Max HP
Engine RPM max = Engine RPM at Max HP
Engine RPM cruise = Desired or estimated cruise rpm
(Cruise or Max) Kts = Speed to work the calculations for
Slip = Propeller efficience. 45% is average for a displacement cruiser.
Gear ratio = 1: Gear ratio of transmission
SL Ratio Adj. = This value will be added (or subtracted, if a negative value) to the calculated S/L ratio.

Key information:

If the "hp required" is greater than the "cruse HP", you have your cruise RPM set too low for your engine parameters.
If the "hp required" is significantly less than the "cruse HP", you have your cruise RPM set too high for your engine parameters.
If the "hp required" is greater than the "Max HP", then your target speed is too high for your engine/hull parameters.
The S/L ratio is calculated automaticaly based on your input. It can be adjusted if necessary, but normally it should be left alone.
If the calculated S/L ratio exceeds S/L MAX, then the results are likely to be non-predictive. Try a lower speed requirement.
SL Ratios of 1.1 - 1.4 are typical of displacement hulls. Semiplaning or planing hulls can go higher.

Typical propeller slip values:

Sailing auxiliary, barges, etc less than 9 Kts............45%
Heavy powerboats, workboats 9 - 15 Kts....................26%
Powerboats, Lightweight Cruisers 15 - 30 Kts..............24%
High speed planing boats 30 - 45 Kts......................20%
V bottom race boats 45 - 90 Kts...........................10%


Note:

it is possible to get irrational answers by irrational input , I.E specifying excessive speed for hull type and length
Any attempt to exceed hull speed (1.34 times the square root of the waterline length in feet) with a displacement hull are likely
to fail unless the hull is extremely fine (multihull) or otherwise exceptional. In such cases, an S/L adjustment would be in order.

2 and 4 bladed props:


For two bladed propellers, multiply the diameter by 1.05, and the pitch by 1.01
For four bladed propellers, multiply the diameter by .94, and the pitch by .98
PROPCALC
  Inputs:
Vessel LWL (ft) =
Vessel Disp (lbs) =
  (max) HP =
  Engine RPM max =
  Engine RPM cruise =
  (Cruise or Max) Kts =
  Slip =
  Gear ratio = 1:
  SL Ratio Adj. =

    Solutions:
  Prop rpm max =
  Prop rpm cruise =
  Pitch =
  Diameter =
  Static Thrust =
  Cruise HP =
  Cruise HP% =
  SL Ratio =
  DL Ratio =
  SL Max =
  HP Required =
