Monday, January 21, 2008

Third World Water Fill

Soooo.. This is where the story begins.....

It was a dark and stormy night ~ Oh, wait that is a future blog post!

It was a sunny and calm day, and Free Spirit was in need of replenishing her water supply. So Captain Smyth decided that we needed to practice a 'third country' water fill. There will be many places in the world that we travel to where there will not be the convenience of a dock to pull up to and fill the tanks. As you can see, during this daring and amazing trick, we also had Raoul at the top of the mast installing the crow's nest netting that he hand made for us.



The first step was to set a bow anchor and basically run aground withe the stern, and then set a stern line ashore.



Shep and Valin Heading in to set the stern line.



Everyone in the crew was directly involved except me, the ships photographer, who wasquite busy on shore taking care of all the gawkers who could not help but wonder what the heck we were doing.



Here is Shep looking a tad bit uncertain about swimming through the alligator infested, dark and dirty Caloosahatchee River, to bring the hose aboard from shore. We had to borrow hose from all around to have enough to reach from the tanks all the way to behind the shower house in the boat yard. I would guess about 200 feet all together.




YAHHHH!!! He made it!! We did successfully fill the tanks, and Raoul was able to finish his work just before sunset.
Special thanks to Raoul for his hard work and dedication to our beautiful and safe crow's nest :-)



posted by CT | 12:53 PM

0 Comments:

Post a Comment

<< Home

Introducing Propcalc 4.0

Use Propcalc to easily match your hull with your engine, transmission, and propeller
Put the known data in the top fields, then hit the Update button to get the answers.
Results, of course, should be verified by a Naval Architect or qualified surveyor.
Data is provided for three bladed propellers of average type
For two or four bladed props, use the modifiers shown below.

Fill out the fields as follows:

Vessel LWL (ft) = Waterline length
Vessel Disp (lbs) = Vessel displacement
(max) HP = Rated Engine Max HP
Engine RPM max = Engine RPM at Max HP
Engine RPM cruise = Desired or estimated cruise rpm
(Cruise or Max) Kts = Speed to work the calculations for
Slip = Propeller efficience. 45% is average for a displacement cruiser.
Gear ratio = 1: Gear ratio of transmission
SL Ratio Adj. = This value will be added (or subtracted, if a negative value) to the calculated S/L ratio.

Key information:

If the "hp required" is greater than the "cruse HP", you have your cruise RPM set too low for your engine parameters.
If the "hp required" is significantly less than the "cruse HP", you have your cruise RPM set too high for your engine parameters.
If the "hp required" is greater than the "Max HP", then your target speed is too high for your engine/hull parameters.
The S/L ratio is calculated automaticaly based on your input. It can be adjusted if necessary, but normally it should be left alone.
If the calculated S/L ratio exceeds S/L MAX, then the results are likely to be non-predictive. Try a lower speed requirement.
SL Ratios of 1.1 - 1.4 are typical of displacement hulls. Semiplaning or planing hulls can go higher.

Typical propeller slip values:

Sailing auxiliary, barges, etc less than 9 Kts............45%
Heavy powerboats, workboats 9 - 15 Kts....................26%
Powerboats, Lightweight Cruisers 15 - 30 Kts..............24%
High speed planing boats 30 - 45 Kts......................20%
V bottom race boats 45 - 90 Kts...........................10%


Note:

it is possible to get irrational answers by irrational input , I.E specifying excessive speed for hull type and length
Any attempt to exceed hull speed (1.34 times the square root of the waterline length in feet) with a displacement hull are likely
to fail unless the hull is extremely fine (multihull) or otherwise exceptional. In such cases, an S/L adjustment would be in order.

2 and 4 bladed props:


For two bladed propellers, multiply the diameter by 1.05, and the pitch by 1.01
For four bladed propellers, multiply the diameter by .94, and the pitch by .98
PROPCALC
  Inputs:
Vessel LWL (ft) =
Vessel Disp (lbs) =
  (max) HP =
  Engine RPM max =
  Engine RPM cruise =
  (Cruise or Max) Kts =
  Slip =
  Gear ratio = 1:
  SL Ratio Adj. =

    Solutions:
  Prop rpm max =
  Prop rpm cruise =
  Pitch =
  Diameter =
  Static Thrust =
  Cruise HP =
  Cruise HP% =
  SL Ratio =
  DL Ratio =
  SL Max =
  HP Required =
